This Brass Safety Switched Lampholder 10mm Entry
is an excellent option for sprucing up a sentimental table lamp or
light fitting of your own design. With the sliding bar switch on the
connection unit, it adds a beautiful timeless feature to the light
fitting.
Comes in 4 parts comprising of the cap which is the
section that screws onto the fixing of the light fitting (or cord grip
for a pendant lamp) the centre connection unit where you will connect
the live (Brown) and neutral (Blue) and Earth (Yellow and Green) then
the top section which will screw over the connection unit and onto the
cap. Not to forget the locking ring (Thicker Ring) that holds the cap
and skirt together and the shade ring the clamp the shade (Thinner
Ring).
The Lampholder as the added feature [Safer Switcher lampholder], requiring a bulb to be fitted for it to become live, meaning that
you cannot turn the lampholder on without the bulb being inserted.
Spec:
- Lamp Cap: BC | B22 | Bayonet Cap
- Height: 60mm
- Diameter: 32mm
- Min Shade Hole Size: 26mm
- Max Shade Hole Size: 32mm
- Max Wattage: 60w
- Thread Entry: M10
- Material: Brass
- Finish: Brass
As with ALL metal lampholders it must be wired with a 3-core flex that provides the correct earth connection.
Safer-Switched Lampholder
- Product Code: SSW1
- Availability: 4
-
£3.99
